EDWARDS AUDIO MM1 MKII PRE PHONO MM Carico fisso a 47kΩ/150pF NUOVO
429,00 € tasse incl.
Attenzione: Ultimi prodotti in magazzino!
The Edwards Audio MM1 Mk2 Phono Stage is a dedicated moving magnet (MM) or high output moving coil (HOMC) RIAA phono stage.Based around the original MM1.PSU1 it has been enhanced in performance with an improved internal PSU and better op-amps. It is unique at the price, with its fully RoHs compliant gold plated custom made double sided PCB’s, folded steel casework with back lit dispaly and 9mm machined frame. It also benefits form TALK Electronics’ buying power with it’s use of 1% thin metal film melf resistors from Vishey plus Panasonic FM series PSU caps and Vishay polyester/polypropylene film capacitors throughout. The RIAA. Equalisation is a rare combination of active bass and passive treble sections with an accuracy that is within 0.25dB across the audio band and signal to noise is very low at -87dB A-weighted. The circuit topology has a totally buffered output section with a very low output impedance to reduce cable effects and improve output drive.
Attention to detail also extends to the custom made plug top power supply,this is unique at this price level for its use of a split rail design using + and – DC power outputs for maximum rejection of RF noise coupled with maximum dynamic range and overload margin. It also uses a gold plated custom made PCB with high quality diodes and snubber caps. This is no normal ‘off the shelf’ PSU as used by the competition.
Traditional TALK styling and performance requirements have not been overlooked either with new back illuminated front panels. The all metal rear panel has RCA connections and an Earth terminal. This is probably the best built and most aesthetic phono stage in it’s class but it doesn’t stop there, it also delivers in the sound department as well, with expansive and detailed sound staging, with real grip over dynamics and bass weight normally associated with more expensive phono stages.
Download the MM1 user manual
|THD Distortion||<0.008% 1kHz|
|Signal to noise||-87db A – weighted/ref 5mV|
|Stereo separation better than||75dB – 20-20kHz|
|Input Loading||47K 120pF|
|Output impedance||Nominal output 185.5mV|
|Max output level||10.3V RMS depending upon input|
|Dimensions WxHxL||114.5mm x 47.5mm x 89mm|
|Power consumption (Max)||4W|
